Appliances
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Kitchen | Samsung | 18 Cu. Ft. Counter-Depth Energy Star French-Door Refrigerator | RF18A5101SR | 32-1/8”W x 70”H x 28-1/8”D | Stainless | All Units under 750 SF Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Kitchen | Samsung | 27.0 Cu. Ft. Side-by-Side Energy Star Refrigerator | RS27T5201SR | 35-7/8”W x 70-1/16”H x 33-1/2”D | Stainless | All Other Units Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Kitchen | Samsung | Slide-in, Electric Range | NSE6DG8100 | 29-15/16”W x 36”H x 28-11/16”D | Stainless | Glass Top Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Kitchen | Samsung | Dishwasher with Hidden Controls | DW80CG4021SR | 23-7/8”W x 35”H x 24-3/4”D | Stainless | Top Controls Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Kitchen | Insinkerator | Disposal | Badger 5 Standard | hp | Provide with power cord |
|
|||
| Kitchen | Samsung | 1.7 cu. ft. Over-the-range Microwave | ME17R7021ES | 29-7/8”W x 17-1/16”H x 16-1/2”D | Stainless | Over-the-range, Recirculating Venting |
|
||
| Kitchen | Samsung | 1.9 cu. ft. Countertop Microwave (Inside Pantry) | MS19DG8500SR | 23-5/8”W x 13-9/32”H x 18-7/16”D | Stainless | Countertop Style; Verify Depth of Pantry (if used). Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Kitchen | Samsung | Under Cabinet Range Hood with LED Lighting | NK30B3000US | 29 15/16”W x 4-15/16” H x 18-7/8” D | Sainless | 350 CFM. In units where microwave is inside the pantry Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Laundry | Samsung | 4.5 cu. ft. Washer | WF45T6000AW | 27”W x 38-3/4”H x 31-3/8”D | White | Front-load with stacking kit as needed, Energy Star |
|
||
| Laundry | Samsung | 4.5 cu. ft. Washer | WF45T6000AW | 27”W x 38-3/4”H x 31-3/8”D | White | Front-load, Energy Star provide with 6” pedestal option |
|
||
| Laundry | Samsung | 7.5 cu. ft. Dryer | DVE45T6000W | 27”W x 38-3/4”H x 31-1/2”D | White | Front-load |
|
||
| Laundry | Samsung | 7.5 cu. ft. Dryer | DVE45T6000W | 27”W x 38-3/4”H x 31-1/2”D | White | Front-load provide with 6” pedestal option |
|
||
| Kitchen | Samsung | Slide-in, Electric Range | NSE6DG8100 | 29-15/16”W x 36”H x 28-11/16”D | Stainless | Glass Top Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
|
||
| Kitchen | Samsung | Dishwasher | DW60R2014US | 23 3/4 in x 32 1/4 in x 23 1/2 in | Stainless | Front Controls |
|
| Samsung Refrigerator RF18A5101SR 32-1/8”W x 70”H x 28-1/8”D Stainless (1) | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | 18 Cu. Ft. Counter-Depth Energy Star French-Door Refrigerator |
| Model # | RF18A5101SR |
| Size | 32-1/8”W x 70”H x 28-1/8”D |
| Color/Finish | Stainless |
| Notes | All Units under 750 SF Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| Samsung Refrigerator RS27T5201SR 35-7/8”W x 70-1/16”H x 33-1/2”D Stainless | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | 27.0 Cu. Ft. Side-by-Side Energy Star Refrigerator |
| Model # | RS27T5201SR |
| Size | 35-7/8”W x 70-1/16”H x 33-1/2”D |
| Color/Finish | Stainless |
| Notes | All Other Units Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| Samsung Slide-in Range NSE6DG8100 29-15/16”W x 36”H x 28-11/16”D Glass Top (1) | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | Slide-in, Electric Range |
| Model # | NSE6DG8100 |
| Size | 29-15/16”W x 36”H x 28-11/16”D |
| Color/Finish | Stainless |
| Notes | Glass Top Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| Samsung Dishwasher DW80CG4021SR 23-7/8”W x 35”H x 24-3/4”D | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | Dishwasher with Hidden Controls |
| Model # | DW80CG4021SR |
| Size | 23-7/8”W x 35”H x 24-3/4”D |
| Color/Finish | Stainless |
| Notes | Top Controls Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| Insinkerator Disposal 1/2 hp | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Insinkerator |
| Description | Disposal |
| Model # | Badger 5 Standard |
| Size | hp |
| Color/Finish | |
| Notes | Provide with power cord |
| Price Point | |
| Product Type | |
| Samsung Stainless Over-the-Range Microwave ME17R7021ES | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | 1.7 cu. ft. Over-the-range Microwave |
| Model # | ME17R7021ES |
| Size | 29-7/8”W x 17-1/16”H x 16-1/2”D |
| Color/Finish | Stainless |
| Notes | Over-the-range, Recirculating Venting |
| Price Point | |
| Product Type | |
| Samsung Countertop Microwave MS19DG8500SR 23-5/8”W x 13-9/32”H x 18-7/16”D | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | 1.9 cu. ft. Countertop Microwave (Inside Pantry) |
| Model # | MS19DG8500SR |
| Size | 23-5/8”W x 13-9/32”H x 18-7/16”D |
| Color/Finish | Stainless |
| Notes | Countertop Style; Verify Depth of Pantry (if used). Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| Samsung Under Cabinet Range NK30B3000US 29 15/16”W x 4-15/16” H x 18-7/8” D | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | Under Cabinet Range Hood with LED Lighting |
| Model # | NK30B3000US |
| Size | 29 15/16”W x 4-15/16” H x 18-7/8” D |
| Color/Finish | Sainless |
| Notes | 350 CFM. In units where microwave is inside the pantry Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| Samsung White Front load Washer WF45T6000AW | |
|---|---|
|
|
|
| Location | Laundry |
| Manufacturer | Samsung |
| Description | 4.5 cu. ft. Washer |
| Model # | WF45T6000AW |
| Size | 27”W x 38-3/4”H x 31-3/8”D |
| Color/Finish | White |
| Notes | Front-load with stacking kit as needed, Energy Star |
| Price Point | |
| Product Type | |
| ADA Samsung Side-by-side washer WF45T6000AW | |
|---|---|
|
|
|
| Location | Laundry |
| Manufacturer | Samsung |
| Description | 4.5 cu. ft. Washer |
| Model # | WF45T6000AW |
| Size | 27”W x 38-3/4”H x 31-3/8”D |
| Color/Finish | White |
| Notes | Front-load, Energy Star provide with 6” pedestal option |
| Price Point | |
| Product Type | |
| Samsung White Front Load Dryer DVE45T6000W | |
|---|---|
|
|
|
| Location | Laundry |
| Manufacturer | Samsung |
| Description | 7.5 cu. ft. Dryer |
| Model # | DVE45T6000W |
| Size | 27”W x 38-3/4”H x 31-1/2”D |
| Color/Finish | White |
| Notes | Front-load |
| Price Point | |
| Product Type | |
| ADA Samsung Side-by-side dryer DVE45T6000W | |
|---|---|
|
|
|
| Location | Laundry |
| Manufacturer | Samsung |
| Description | 7.5 cu. ft. Dryer |
| Model # | DVE45T6000W |
| Size | 27”W x 38-3/4”H x 31-1/2”D |
| Color/Finish | White |
| Notes | Front-load provide with 6” pedestal option |
| Price Point | |
| Product Type | |
| Samsung Slide-in Range NSE6DG8100 29-15/16”W x 36”H x 28-11/16”D Glass Top (1) | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | Slide-in, Electric Range |
| Model # | NSE6DG8100 |
| Size | 29-15/16”W x 36”H x 28-11/16”D |
| Color/Finish | Stainless |
| Notes | Glass Top Michele Friedenburg m.friedenbur@sea.samsung.com (561) 290-9939 |
| Price Point | |
| Product Type | |
| ADA Samsung Stainless Dishwasher DW60R2014US | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Samsung |
| Description | Dishwasher |
| Model # | DW60R2014US |
| Size | 23 3/4 in x 32 1/4 in x 23 1/2 in |
| Color/Finish | Stainless |
| Notes | Front Controls |
| Price Point | |
| Product Type | |
Bath Accessories
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Bathroom | Pamex | Surface Paper Holder | BC14-42 | 7-3/8” x 1-3/4” | Matte Black |
|
|||
| Bathroom | Pamex | Single Robe Hook | BC14-21 | 2” x 2” Diameter | Matte Black | See Architectural Unit Plans for Quantity | NOVEL, RENDER, HARMON |
|
|
| Bathroom | Pamex | Towel Bar Set | BC14-15824 | 25-3/4" x 2-1/8" | Matte Black | See Architectural Unit Plans for Quantity |
|
||
| Bathroom | FGD | Semi-Frameless | 80" Tall | Matte Black | Semi-frameless doors with clear glass and 6” tubular pull (Confirm no diagonal bracing required) |
|
|||
| Bathroom | FGD | Semi-Frameless | 72" Tall | Matte Black | Semi-frameless doors with clear glass and 6” tubular pull (Confirm no diagonal bracing required) |
|
|||
| Rectangular Metal Framed Mirror | 711BLK | Mirror sized per drawings | Matte Black | Separate mirrors for each sink (one for single sink, two for double sink) |
|
||||
| Bathroom | Pamex | Curved Shower Rod | BSR-573/673 | 60” | Matte Black | Only in Tub/shower combo locations |
|
| Toilet Paper Holder Pamex BC14-42 Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pamex |
| Description | Surface Paper Holder |
| Model # | BC14-42 |
| Size | 7-3/8” x 1-3/4” |
| Color/Finish | Matte Black |
| Notes | |
| Price Point | |
| Product Type | |
| Bathroom Robe Hook Pamex BC14-21 Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pamex |
| Description | Single Robe Hook |
| Model # | BC14-21 |
| Size | 2” x 2” Diameter |
| Color/Finish | Matte Black |
| Notes | See Architectural Unit Plans for Quantity |
| Price Point | |
| Product Type | NOVEL, RENDER, HARMON |
| Towel Bar Pamex BC14-15824 Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pamex |
| Description | Towel Bar Set |
| Model # | BC14-15824 |
| Size | 25-3/4" x 2-1/8" |
| Color/Finish | Matte Black |
| Notes | See Architectural Unit Plans for Quantity |
| Price Point | |
| Product Type | |
| FGD Shower Door (Swing) Semi-Frameless 80" Tall Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | FGD |
| Description | Semi-Frameless |
| Model # | |
| Size | 80" Tall |
| Color/Finish | Matte Black |
| Notes | Semi-frameless doors with clear glass and 6” tubular pull (Confirm no diagonal bracing required) |
| Price Point | |
| Product Type | |
| FGD Shower Door (Swing) ADA 72" Tall Matte Black Semi-Frameless | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | FGD |
| Description | Semi-Frameless |
| Model # | |
| Size | 72" Tall |
| Color/Finish | Matte Black |
| Notes | Semi-frameless doors with clear glass and 6” tubular pull (Confirm no diagonal bracing required) |
| Price Point | |
| Product Type | |
| Vanity Mirror Precision Frameworks 711BLK Matte Black | |
|---|---|
|
|
| Location | |
| Manufacturer | |
| Description | Rectangular Metal Framed Mirror |
| Model # | 711BLK |
| Size | Mirror sized per drawings |
| Color/Finish | Matte Black |
| Notes | Separate mirrors for each sink (one for single sink, two for double sink) |
| Price Point | |
| Product Type | |
| Shower Rod Pamex BSR-573/673 Curved Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pamex |
| Description | Curved Shower Rod |
| Model # | BSR-573/673 |
| Size | 60” |
| Color/Finish | Matte Black |
| Notes | Only in Tub/shower combo locations |
| Price Point | |
| Product Type | |
Cabinets & Countertops
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Kitchen | Republic | Aspen | 42" Upper Cabinets | Color TBD From standard selections | Full-overlay, frameless with valence/filler included around refrigerator and cabinets, leaving 1-1/2” max gaps between. Drawers to be wood boxes with full extension, soft-close slides. Trash pull-outs require full extension soft-close slides also. Shoe Moulding is included at all cabinet bases. |
|
|||
| Bathroom | Republic | Aspen | 34" High Vanities | Color TBD From standard selections | Full-overlay, frameless, Drawers to be wood boxes and have full extension, soft-close slides. |
|
|||
| Kitchen | Rev-A-Shelf | Top Mount Double Trash Pullout | RV-53TM1835GSCDM2-FL | Double 35 QT cans | Grey | Trash pull-outs require full extension soft-close slides and dual canister. |
|
||
| Kitchen | Rev-A-Shelf | Top Mount Double Trash Pullout | RV-53TM1850GSCDM2-FL | Double 50 QT cans | Grey | Trash pull-outs require full extension soft-close slides and dual canister. |
|
||
| Units | Berenson | Pull spec - drawer | 1060-4055-P | 3" Edge Pull | Matte Black | Edge Pull |
|
||
| Kitchen | Silestone by Cosentino | Quartz | Pencil Edge | 3cm | Et Calacatta Gold |
|
|||
| Units | Silestone by Cosentino | Quartz Level 1 | Pencil Edge | 3cm | Miami Vena (Basis of Design Similar Color Selection by Luxor) | Franciso Repiso Ferris frepiso@cosentino.com (281) 744-6854 |
|
||
| Bathroom | Amerisink | Square Undermount Sink | AS225 | 20" x 15"x7.5” | White (020) |
|
|||
| Bathroom | Amerisink | Square Undermount Sink | AS240 | 19.5" x 14.25"x6.5” | White (020) |
|
|||
| Kitchen | Amerisink | Kitchen Sink - Undermount | AS152 | 32"x19"x9" depth | Stainless | Squared edges oversize/depth single bowl |
|
||
| Kitchen | Amerisink | Kitchen Sink – Undermount | AS1526 | 31.25”x18”x5.5” | Stainless | Squared edges oversize/ADA depth single bowl. |
|
| Kitchen & Island Republic Aspen 42" Upper Cabinets | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Republic |
| Description | Aspen |
| Model # | |
| Size | 42" Upper Cabinets |
| Color/Finish | Color TBD From standard selections |
| Notes | Full-overlay, frameless with valence/filler included around refrigerator and cabinets, leaving 1-1/2” max gaps between. Drawers to be wood boxes with full extension, soft-close slides. Trash pull-outs require full extension soft-close slides also. Shoe Moulding is included at all cabinet bases. |
| Price Point | |
| Product Type | |
| Bathroom Vanity Republic Aspen 34" High Vanities | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Republic |
| Description | Aspen |
| Model # | |
| Size | 34" High Vanities |
| Color/Finish | Color TBD From standard selections |
| Notes | Full-overlay, frameless, Drawers to be wood boxes and have full extension, soft-close slides. |
| Price Point | |
| Product Type | |
| Trash Pullout Double 35QT Rev-A-Shelf RV-53TM1835GSCDM2-FL | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Rev-A-Shelf |
| Description | Top Mount Double Trash Pullout |
| Model # | RV-53TM1835GSCDM2-FL |
| Size | Double 35 QT cans |
| Color/Finish | Grey |
| Notes | Trash pull-outs require full extension soft-close slides and dual canister. |
| Price Point | |
| Product Type | |
| Trash Pullout Double 50QT Rev-A-Shelf RV-53TM1850GSCDM2-FL | |
|---|---|
|
|
|
| Location | Kitchen |
| Manufacturer | Rev-A-Shelf |
| Description | Top Mount Double Trash Pullout |
| Model # | RV-53TM1850GSCDM2-FL |
| Size | Double 50 QT cans |
| Color/Finish | Grey |
| Notes | Trash pull-outs require full extension soft-close slides and dual canister. |
| Price Point | |
| Product Type | |
| Cabinet Hardware Berenson 3" Edge Pull 1060-4055-P Matte Black | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Berenson |
| Description | Pull spec - drawer |
| Model # | 1060-4055-P |
| Size | 3" Edge Pull |
| Color/Finish | Matte Black |
| Notes | Edge Pull |
| Price Point | |
| Product Type | |
| Kitchen Countertops Silestone by Cosentino 3cm Et Calacatta Gold | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Silestone by Cosentino |
| Description | Quartz |
| Model # | Pencil Edge |
| Size | 3cm |
| Color/Finish | Et Calacatta Gold |
| Notes | |
| Price Point | |
| Product Type | |
| Kitchen Silestone Countertop Quartz 3cm Miami Vena | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Silestone by Cosentino |
| Description | Quartz Level 1 |
| Model # | Pencil Edge |
| Size | 3cm |
| Color/Finish | Miami Vena (Basis of Design Similar Color Selection by Luxor) |
| Notes | Franciso Repiso Ferris frepiso@cosentino.com (281) 744-6854 |
| Price Point | |
| Product Type | |
| Vanity Sink Amerisink White 20" x 15"x7.5” | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Amerisink |
| Description | Square Undermount Sink |
| Model # | AS225 |
| Size | 20" x 15"x7.5” |
| Color/Finish | White (020) |
| Notes | |
| Price Point | |
| Product Type | |
| ADA Vanity Sink Amerisink AS240 White 19.5" x 14.25"x6.5” | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Amerisink |
| Description | Square Undermount Sink |
| Model # | AS240 |
| Size | 19.5" x 14.25"x6.5” |
| Color/Finish | White (020) |
| Notes | |
| Price Point | |
| Product Type | |
| Kitchen Sink Amerisink AS152 Stainless | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Amerisink |
| Description | Kitchen Sink - Undermount |
| Model # | AS152 |
| Size | 32"x19"x9" depth |
| Color/Finish | Stainless |
| Notes | Squared edges oversize/depth single bowl |
| Price Point | |
| Product Type | |
| Kitchen Sink (ADA) Amerisink AS1526 Stainless | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Amerisink |
| Description | Kitchen Sink – Undermount |
| Model # | AS1526 |
| Size | 31.25”x18”x5.5” |
| Color/Finish | Stainless |
| Notes | Squared edges oversize/ADA depth single bowl. |
| Price Point | |
| Product Type | |
Doors & Hardware
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Units | Masonite | Single Panel, Craftsman / Square Profile, Solid Core | Lincoln Park | 7' | Primed MDF |
|
|||
| Unit Doors Interior | Masonite | 2-Panel, Craftsman / Square Profile, Hollow Core | Logan Series | 6’-8” | Primed MDF |
|
|||
| Patio Door Exterior | Therma-Tru | 8' | Smooth Door, Clear Glass | Tempered Glass if Required by code |
|
||||
| Electronic Deadbolt Unit Entries | Schlage Control | Smart Lock with Addison trim | Addison | Matte Black | Unit entry doors. Provide with Stratis software package. All electronic door fobs to be dual credential and coordinated with access control vendor for compatibility. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
|
|||
| Patio | Schlage | Solstice | J10SOL622 | Matte Black | Passage Set Function. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
|
|||
| Patio | Taymor | Vega Square Rose Lever | Lever (30-D0067X4BLK), model number dependent on function | Matte Black | Keyed Lock on Basement/1st Floor Only & No Lock on all Upper Floors |
|
|||
| Unit Doors Interior | Taymor | Vega Square Rose Lever | Lever (30-D0067X4BLK), model number dependent on function. | Matte Black | Privacy Locks on Bathroom & Bedroom Doors |
|
|||
| Units | Schlage | Solstice | J10SOL622 | Matte Black | Privacy function at all bedrooms and bathrooms. Passage function at all other doors. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
|
|||
| Unit Entries | Schlage | Solstice | J10SOL622 | Matte Black | Passage Set Function. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
|
|||
| Unit Entries | Deltana | Standard Steel Hinge | S44U1B-R | 4x4 | All hinges to match door hardware (Do Not Paint) – Matte Black |
|
|||
| Unit Entries | Deltana | Standard HD Spring Hinge | DSH44U1B | 4x4 | All hinges to match door hardware (Do Not Paint) – Matte Black | Hinge must be UL Rated Heavy Duty hinge for rated openings |
|
||
| Units | Deltana | S35R5BK1B | 3.5”x3.5” | All hinges to match door hardware (Do Not Paint) – Matte Black | No paintable hinges |
|
|||
| Unit Interior | Ives | Spring Door Stop | 63FLBK | 3" | Matte Black | Provide at wall base where space available |
|
||
| Unit Doors Interior | Door Saver | Hinge Pin Stop | DoorSaver3 | Matte Black | Provide at doors where base door stop cannot be provided. |
|
|||
| Unit Interior | Pamex | Single Robe Hook | BC14-21 | 2” x 2” Diameter | Matte Black | See Architectural Unit Plans for Quantity |
|
| Unit Entry Door Masonite Lincoln Park 7' | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Masonite |
| Description | Single Panel, Craftsman / Square Profile, Solid Core |
| Model # | Lincoln Park |
| Size | 7' |
| Color/Finish | Primed MDF |
| Notes | |
| Price Point | |
| Product Type | |
| Unit Interior Door Masonite 2-Panel 6'8" Logan | |
|---|---|
|
|
| Location | Unit Doors Interior |
| Manufacturer | Masonite |
| Description | 2-Panel, Craftsman / Square Profile, Hollow Core |
| Model # | Logan Series |
| Size | 6’-8” |
| Color/Finish | Primed MDF |
| Notes | |
| Price Point | |
| Product Type | |
| Patio Door Therma-Tru 8' | |
|---|---|
|
|
| Location | Patio Door Exterior |
| Manufacturer | Therma-Tru |
| Description | |
| Model # | |
| Size | 8' |
| Color/Finish | Smooth Door, Clear Glass |
| Notes | Tempered Glass if Required by code |
| Price Point | |
| Product Type | |
| Schlage Smart Lock Addison Trim | |
|---|---|
|
|
| Location | Electronic Deadbolt Unit Entries |
| Manufacturer | Schlage Control |
| Description | Smart Lock with Addison trim |
| Model # | Addison |
| Size | |
| Color/Finish | Matte Black |
| Notes | Unit entry doors. Provide with Stratis software package. All electronic door fobs to be dual credential and coordinated with access control vendor for compatibility. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
| Price Point | |
| Product Type | |
| Patio Door Handle Schlage J10SOL622 Matte Black | |
|---|---|
|
|
| Location | Patio |
| Manufacturer | Schlage |
| Description | Solstice |
| Model # | J10SOL622 |
| Size | |
| Color/Finish | Matte Black |
| Notes | Passage Set Function. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
| Price Point | |
| Product Type | |
| Patio Door Hardware Taymor 30-D0067X4BLK Matte Black Handle | |
|---|---|
|
|
| Location | Patio |
| Manufacturer | Taymor |
| Description | Vega Square Rose Lever |
| Model # | Lever (30-D0067X4BLK), model number dependent on function |
| Size | |
| Color/Finish | Matte Black |
| Notes | Keyed Lock on Basement/1st Floor Only & No Lock on all Upper Floors |
| Price Point | |
| Product Type | |
| Unit Interior Door Hardware Taymor Matte Black | |
|---|---|
|
|
| Location | Unit Doors Interior |
| Manufacturer | Taymor |
| Description | Vega Square Rose Lever |
| Model # | Lever (30-D0067X4BLK), model number dependent on function. |
| Size | |
| Color/Finish | Matte Black |
| Notes | Privacy Locks on Bathroom & Bedroom Doors |
| Price Point | |
| Product Type | |
| Unit Interior Door Handle Schlage J10SOL622 Matte Black | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Schlage |
| Description | Solstice |
| Model # | J10SOL622 |
| Size | |
| Color/Finish | Matte Black |
| Notes | Privacy function at all bedrooms and bathrooms. Passage function at all other doors. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
| Price Point | |
| Product Type | |
| Unit Entry Door Handle Schlage J10SOL622 Solstice Matte Black | |
|---|---|
|
|
| Location | Unit Entries |
| Manufacturer | Schlage |
| Description | Solstice |
| Model # | J10SOL622 |
| Size | |
| Color/Finish | Matte Black |
| Notes | Passage Set Function. John Blackwelder John.Blackwelder@allegion.com (803) 361-6892 |
| Price Point | |
| Product Type | |
| Unit Entry Door Standard Hinge Deltana 4x4 S44U1B-R | |
|---|---|
|
|
| Location | Unit Entries |
| Manufacturer | Deltana |
| Description | Standard Steel Hinge |
| Model # | S44U1B-R |
| Size | 4x4 |
| Color/Finish | All hinges to match door hardware (Do Not Paint) – Matte Black |
| Notes | |
| Price Point | |
| Product Type | |
| Unit Entry Door Spring Hinges Deltana 4x4 DSH44U1B | |
|---|---|
|
|
| Location | Unit Entries |
| Manufacturer | Deltana |
| Description | Standard HD Spring Hinge |
| Model # | DSH44U1B |
| Size | 4x4 |
| Color/Finish | All hinges to match door hardware (Do Not Paint) – Matte Black |
| Notes | Hinge must be UL Rated Heavy Duty hinge for rated openings |
| Price Point | |
| Product Type | |
| Interior Door Hinge Deltana S35R5BK1B 3.5”x3.5” | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Deltana |
| Description | |
| Model # | S35R5BK1B |
| Size | 3.5”x3.5” |
| Color/Finish | All hinges to match door hardware (Do Not Paint) – Matte Black |
| Notes | No paintable hinges |
| Price Point | |
| Product Type | |
| Unit Interior Door Hardware Ives Spring Door Stop Matte Black | |
|---|---|
|
|
| Location | Unit Interior |
| Manufacturer | Ives |
| Description | Spring Door Stop |
| Model # | 63FLBK |
| Size | 3" |
| Color/Finish | Matte Black |
| Notes | Provide at wall base where space available |
| Price Point | |
| Product Type | |
| Unit Interior Door Hardware Door Saver Hinge Pin Stop Matte Black | |
|---|---|
|
|
| Location | Unit Doors Interior |
| Manufacturer | Door Saver |
| Description | Hinge Pin Stop |
| Model # | DoorSaver3 |
| Size | |
| Color/Finish | Matte Black |
| Notes | Provide at doors where base door stop cannot be provided. |
| Price Point | |
| Product Type | |
| Entry Bench Hooks Pamex BC14-21 Matte Black | |
|---|---|
|
|
| Location | Unit Interior |
| Manufacturer | Pamex |
| Description | Single Robe Hook |
| Model # | BC14-21 |
| Size | 2” x 2” Diameter |
| Color/Finish | Matte Black |
| Notes | See Architectural Unit Plans for Quantity |
| Price Point | |
| Product Type | |
Flooring & Hard Surfaces
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Kitchen | Daltile | Finish Line | FL91 | 4”x12” | White | Running bond pattern with 1/8" joints - Grout: Laticrete - Color TBD. All exposed tile edges to be trimmed with Schluter strip to match tile or plumbing hardware (TBD). Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
|
||
| Bathroom | Daltile | Mythology Wall Tile | MY91 | 4”x12” | Olympus | Running bond pattern with 1/8" joints - Grout: Laticrete - Color TBD. All exposed tile edges to be trimmed with Schluter strip to match tile or plumbing hardware (TBD). Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
|
||
| Bathroom | Daltile | Mythology Wall Tile | MY91 | 4”x12” | Olympus | Running bond pattern with 1/8" joints - Grout: Laticrete - Color TBD. All exposed tile edges to be trimmed with Schluter strip to match tile or plumbing hardware (TBD). Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
|
||
| Bathroom | Daltile | Corner shower shelf | BA780 | 8”x8” | Match tile color | Provide two shelves (one low/ one high) in stand alone showers and one (high) in all tubs Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
|
||
| Bathroom Flooring | Cobalt Katanga | 12 mil LVP | 7"x48" | Myrtle | 2.0 mm thickness with 12 mil wear layer. Provide 1/4” Acoustimat sound mat underneath all hard surface finishes. LVP throughout all Units on ground level and LVP to be provided throughout WIC’s where W/D installed. Hannah Verschoore hverschoore@spartansurfaces.com (214) 422-4805 | NOVEL |
|
||
| Units | Cobalt Katanga | 12 mil LVP | 7”x48” | Myrtle | 2.0 mm thickness with 12 mil wear layer. Provide 1/4” Acoustimat sound mat underneath all hard surface finishes. LVP throughout all Units on ground level and LVP to be provided throughout WIC’s where W/D installed. Hannah Verschoore hverschoore@spartansurfaces.com (214) 422-4805 |
|
|||
| Units | Mohawk | Broadloom Carpet | Enriched Texture II; Provide with 6# Carpet Pad | Artic Air 807 | Except Studio Units and Ground Floor Units – LVP to be kept throughout the Entire Unit Nate Kepner Nate_kepner@mohawkind.com (206) 530-4395 |
|
|||
| Units | Schluter VinPro-U 5/16 | LVT to carpet transition strip | VPUL80ACGB | Lengths as shown on drawings | Brushed nickel anodized | Transition strip from carpet to vinyl flooring |
|
||
| Unit Entries | Daltile | Double Hollywood Bevel | G771 | 4" | Absolute Black | Polished Granite |
|
| Kitchen Backsplash Daltile FL91 White 4”x12” | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Daltile |
| Description | Finish Line |
| Model # | FL91 |
| Size | 4”x12” |
| Color/Finish | White |
| Notes | Running bond pattern with 1/8" joints - Grout: Laticrete - Color TBD. All exposed tile edges to be trimmed with Schluter strip to match tile or plumbing hardware (TBD). Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
| Price Point | |
| Product Type | |
| Bathroom wall/shower surround Daltile MY91 Olympus 4”x12” | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Daltile |
| Description | Mythology Wall Tile |
| Model # | MY91 |
| Size | 4”x12” |
| Color/Finish | Olympus |
| Notes | Running bond pattern with 1/8" joints - Grout: Laticrete - Color TBD. All exposed tile edges to be trimmed with Schluter strip to match tile or plumbing hardware (TBD). Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
| Price Point | |
| Product Type | |
| Tub/Shower Combo Daltile MY91 Olympus 4”x12” | |
|---|---|
|
|
|
| Location | Bathroom |
| Manufacturer | Daltile |
| Description | Mythology Wall Tile |
| Model # | MY91 |
| Size | 4”x12” |
| Color/Finish | Olympus |
| Notes | Running bond pattern with 1/8" joints - Grout: Laticrete - Color TBD. All exposed tile edges to be trimmed with Schluter strip to match tile or plumbing hardware (TBD). Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
| Price Point | |
| Product Type | |
| Tub/Shower Corner Shelves Dalile BA780 8”x8” | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Daltile |
| Description | Corner shower shelf |
| Model # | BA780 |
| Size | 8”x8” |
| Color/Finish | Match tile color |
| Notes | Provide two shelves (one low/ one high) in stand alone showers and one (high) in all tubs Jonathan Studioso Jonathan.Studioso@daltile.com (704) 516-6310 |
| Price Point | |
| Product Type | |
| Bathroom Flooring Cobalt Katanga Myrtle | |
|---|---|
|
|
| Location | Bathroom Flooring |
| Manufacturer | Cobalt Katanga |
| Description | 12 mil LVP |
| Model # | |
| Size | 7"x48" |
| Color/Finish | Myrtle |
| Notes | 2.0 mm thickness with 12 mil wear layer. Provide 1/4” Acoustimat sound mat underneath all hard surface finishes. LVP throughout all Units on ground level and LVP to be provided throughout WIC’s where W/D installed. Hannah Verschoore hverschoore@spartansurfaces.com (214) 422-4805 |
| Price Point | |
| Product Type | NOVEL |
| Unit Flooring Cobalt Katanga Myrtle 7”x48” | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Cobalt Katanga |
| Description | 12 mil LVP |
| Model # | |
| Size | 7”x48” |
| Color/Finish | Myrtle |
| Notes | 2.0 mm thickness with 12 mil wear layer. Provide 1/4” Acoustimat sound mat underneath all hard surface finishes. LVP throughout all Units on ground level and LVP to be provided throughout WIC’s where W/D installed. Hannah Verschoore hverschoore@spartansurfaces.com (214) 422-4805 |
| Price Point | |
| Product Type | |
| Bedroom Flooring Mohawk Broadloom Carpet Artic Air 807 | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Mohawk |
| Description | Broadloom Carpet |
| Model # | Enriched Texture II; Provide with 6# Carpet Pad |
| Size | |
| Color/Finish | Artic Air 807 |
| Notes | Except Studio Units and Ground Floor Units – LVP to be kept throughout the Entire Unit Nate Kepner Nate_kepner@mohawkind.com (206) 530-4395 |
| Price Point | |
| Product Type | |
| Flooring Transition Strip Schluter VinPro VPUL80ACGB Brushed Nickel | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Schluter VinPro-U 5/16 |
| Description | LVT to carpet transition strip |
| Model # | VPUL80ACGB |
| Size | Lengths as shown on drawings |
| Color/Finish | Brushed nickel anodized |
| Notes | Transition strip from carpet to vinyl flooring |
| Price Point | |
| Product Type | |
| Unit Entry Threshold Daltile 4" Absolute Black | |
|---|---|
|
|
| Location | Unit Entries |
| Manufacturer | Daltile |
| Description | Double Hollywood Bevel |
| Model # | G771 |
| Size | 4" |
| Color/Finish | Absolute Black |
| Notes | Polished Granite |
| Price Point | |
| Product Type | |
Interior Paint Colors
| Location | Manufacturer | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|
| Walls | Sherwin Williams | SW 7028 - Incredible White - 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE30 Series Flat Latex. Use PE20 Series Eggshell Latex in Unit Bathrooms. |
|
|||
| Ceilings | Sherwin Williams | SW Pure White - 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE30 Series Flat Latex. Use PE20 Series Eggshell Latex in Unit Bathrooms. | Flat paint except in bathrooms (eggshell) Holt Faucette holt.faucette@sherwin.com (407) 448-2359 |
|
||
| Unit Trim | Sherwin Williams | SW Pure White - 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE31 Series Semi-Gloss. |
|
|||
| Patio Door Exterior | Sherwin Williams | Primer - All Surface Enamel Interior/Exterior Latex Primer A41W01210 (dried to 1.5 mils thickness min.). Finish – Pro Industrial Multi-Surface Acrylic B-66-1550 Series (dried to 1.5 mils thickness min.) | Semi-gloss paint for patio door. See Arch. Drawings for color. |
|
||
| Corridor Walls (BASE) | Sherwin Williams | 1 coat ProMar 200 Latex Primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B20-2600. |
|
|||
| Corridor Walls (ACCENT) | Sherwin Williams | 1 coat ProMar 200 Latex primer B28W02600, 2 coats Painters Edge PE30 Series Flat latex |
|
|||
| Corridor Trim (BASE) | Sherwin Williams | 1 coat ProMar 200 Latex primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B31-2600 |
|
|||
| Corridor Trim (ACCENT) | Sherwin Williams | 1 coat ProMar 200 Latex primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B31-2600 |
|
|||
| Building Doors & Trim | Sherwin Williams | 1 coat ProMar 200 Latex primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B31-2600 | NOVEL |
|
||
| Mechanical Rooms Walls & Ceilings | Sherwin Williams | 1 coat Painters Edge latex PE30 Series Primer, 1 coat Painters Edge PE20 Series Eggshell Latex. 1 Coat Painters Edge PE30 Series Flat Latex (ceilings). |
|
|||
| Storage Room Walls & Ceilings | Sherwin Williams | 1 coat painters Edge latex PE30 Series Primer. Use 1 coat PE20 Series Eggshell Latex on walls & ceilings | Flat (ceilings)/Eggshell (walls). See Arch/ID Drawings for color(s). Holt Faucette holt.faucette@sherwin.com (407) 448-2359 |
|
||
| Stair Wells Walls & Ceilings | Sherwin Williams | 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE30 Series Flat Latex (ceilings). Use 1 coat PE20 Series Eggshell Latex on walls | Flat (ceilings)/Eggshell (walls). |
|
| Walls Sherwin Williams SW 7028 - Incredible White | |
|---|---|
|
|
|
| Location | Walls |
| Manufacturer | Sherwin Williams |
| Color/Finish | SW 7028 - Incredible White - 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE30 Series Flat Latex. Use PE20 Series Eggshell Latex in Unit Bathrooms. |
| Notes | |
| Price Point | |
| Product Type | |
| Ceilings Sherwin Williams SW Pure White | |
|---|---|
|
|
| Location | Ceilings |
| Manufacturer | Sherwin Williams |
| Color/Finish | SW Pure White - 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE30 Series Flat Latex. Use PE20 Series Eggshell Latex in Unit Bathrooms. |
| Notes | Flat paint except in bathrooms (eggshell) Holt Faucette holt.faucette@sherwin.com (407) 448-2359 |
| Price Point | |
| Product Type | |
| Unit Trim Sherwin Williams SW Pure White | |
|---|---|
|
|
| Location | Unit Trim |
| Manufacturer | Sherwin Williams |
| Color/Finish | SW Pure White - 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE31 Series Semi-Gloss. |
| Notes | |
| Price Point | |
| Product Type | |
| Patio Door Exterior Sherwin Williams | |
|---|---|
|
|
|
| Location | Patio Door Exterior |
| Manufacturer | Sherwin Williams |
| Color/Finish | Primer - All Surface Enamel Interior/Exterior Latex Primer A41W01210 (dried to 1.5 mils thickness min.). Finish – Pro Industrial Multi-Surface Acrylic B-66-1550 Series (dried to 1.5 mils thickness min.) |
| Notes | Semi-gloss paint for patio door. See Arch. Drawings for color. |
| Price Point | |
| Product Type | |
| Corridor Walls (BASE) Sherwin Williams ProMar | |
|---|---|
|
|
|
| Location | Corridor Walls (BASE) |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat ProMar 200 Latex Primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B20-2600. |
| Notes | |
| Price Point | |
| Product Type | |
| Corridor Walls (ACCENT) Sherwin Williams ProMar | |
|---|---|
|
|
|
| Location | Corridor Walls (ACCENT) |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat ProMar 200 Latex primer B28W02600, 2 coats Painters Edge PE30 Series Flat latex |
| Notes | |
| Price Point | |
| Product Type | |
| Corridor Trim (BASE) Sherwin Williams ProMar | |
|---|---|
|
|
|
| Location | Corridor Trim (BASE) |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat ProMar 200 Latex primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B31-2600 |
| Notes | |
| Price Point | |
| Product Type | |
| Corridor Trim (ACCENT) Sherwin Williams ProMar | |
|---|---|
|
|
|
| Location | Corridor Trim (ACCENT) |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat ProMar 200 Latex primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B31-2600 |
| Notes | |
| Price Point | |
| Product Type | |
| Building Doors & Trim Sherwin Williams ProMar | |
|---|---|
|
|
|
| Location | Building Doors & Trim |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat ProMar 200 Latex primer B28W02600, 2 coats ProMar 200 Latex Semi-gloss B31-2600 |
| Notes | |
| Price Point | |
| Product Type | NOVEL |
| Mechanical Rooms Walls & Ceilings Sherwin Williams Painters Edge | |
|---|---|
|
|
|
| Location | Mechanical Rooms Walls & Ceilings |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat Painters Edge latex PE30 Series Primer, 1 coat Painters Edge PE20 Series Eggshell Latex. 1 Coat Painters Edge PE30 Series Flat Latex (ceilings). |
| Notes | |
| Price Point | |
| Product Type | |
| Storage Room Walls & Ceilings Sherwin Williams Painters Edge | |
|---|---|
|
|
|
| Location | Storage Room Walls & Ceilings |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat painters Edge latex PE30 Series Primer. Use 1 coat PE20 Series Eggshell Latex on walls & ceilings |
| Notes | Flat (ceilings)/Eggshell (walls). See Arch/ID Drawings for color(s). Holt Faucette holt.faucette@sherwin.com (407) 448-2359 |
| Price Point | |
| Product Type | |
| Stair Wells Walls & Ceilings Sherwin Williams Painters Edge | |
|---|---|
|
|
|
| Location | Stair Wells Walls & Ceilings |
| Manufacturer | Sherwin Williams |
| Color/Finish | 1 coat Painters Edge Latex PE30 Series primer, 1 coat Painters Edge PE30 Series Flat Latex (ceilings). Use 1 coat PE20 Series Eggshell Latex on walls |
| Notes | Flat (ceilings)/Eggshell (walls). |
| Price Point | |
| Product Type | |
Lighting Fixtures
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Units | Legacy Lighting | LED 52" 3-Blade Arden Ceiling Fan, Frosted White, Wall Control | F-1030 WH | 52" | Frosted White | Fans in all bedrooms & pre-wire living room. Provide with LED lamps |
|
||
| Units | Westinghouse | 7788500 | Four fan speeds and light dimmer. Confirm compatibility with provided fan. |
|
|||||
| Kitchen | Legacy Lighting | Single Light Pendant | LGL-745-BK | 7.75"DIA X 8.5"H X 131.25"OAH | Round, Black Exterior Finish Frosted Shade | See Plans for Locations. Centered over island. Provide with LED Bulb and ensure light/ switch are dimmable. |
|
||
| Units | Legacy Lighting | 7” 3000K LED Flush Mount | LED-30097 WH | 7" | Round, Matte White Finish |
|
|||
| Units | Legacy Lighting | 5” 3000K LED Flush Mount | LED-30095 WH | 7" | Round, Matte White Finish |
|
|||
| Patio | Legacy Lighting | 6” 3000K LED Flush Mount | 57697WTBK | 6" | Square, Matte Black Finish | Wet Label / Rated in Bathroom Areas and Balcony Areas |
|
||
| Patio | Legacy Lighting | Wall/Step Light | LOL470BK | 3.75"EXT X 7-7/8"H X 4.5"W2 | Matte Black | Wet Label |
|
||
| Bathroom | Legacy Lighting | Sconce | LED-22464 BK | 24” wide | Black | Install horizontally above mirror, one fixture per sink bowl. When one sink is provided, center single fixture over vanity. When two sinks are provided, center fixture over each sink. |
|
||
| Units | Leviton | Decora Plus | R62-16252-0WS | White |
|
||||
| Units | Leviton | Decora Plus | T5833-W (Type A and C Charger) | White | Locations as shown in plans |
|
|||
| Units | Honeywell | Lyric T6 Smart Thermostat | TH6220WF2006/U | White |
|
||||
| Units | Leviton | Decora Plus | R72-05601-2WS | White | 1 dimmer switch per unit (kitchen Pendants) |
|
| Ceiling Fan Legacy Lighting 52" F-1030 WH Frosted White | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Legacy Lighting |
| Description | LED 52" 3-Blade Arden Ceiling Fan, Frosted White, Wall Control |
| Model # | F-1030 WH |
| Size | 52" |
| Color/Finish | Frosted White |
| Notes | Fans in all bedrooms & pre-wire living room. Provide with LED lamps |
| Price Point | |
| Product Type | |
| Light/Fan Combo Switch Westinghouse 7788500 | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Westinghouse |
| Description | |
| Model # | 7788500 |
| Size | |
| Color/Finish | |
| Notes | Four fan speeds and light dimmer. Confirm compatibility with provided fan. |
| Price Point | |
| Product Type | |
| Island Pendants Legacy Lighting Single LGL-745-BK Round Black | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Legacy Lighting |
| Description | Single Light Pendant |
| Model # | LGL-745-BK |
| Size | 7.75"DIA X 8.5"H X 131.25"OAH |
| Color/Finish | Round, Black Exterior Finish Frosted Shade |
| Notes | See Plans for Locations. Centered over island. Provide with LED Bulb and ensure light/ switch are dimmable. |
| Price Point | |
| Product Type | |
| Legacy Lighting 7" 3000K LED-30097 WH | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Legacy Lighting |
| Description | 7” 3000K LED Flush Mount |
| Model # | LED-30097 WH |
| Size | 7" |
| Color/Finish | Round, Matte White Finish |
| Notes | |
| Price Point | |
| Product Type | |
| Legacy Lighting 5" 3000K LED-30095 WH | |
|---|---|
|
|
|
| Location | Units |
| Manufacturer | Legacy Lighting |
| Description | 5” 3000K LED Flush Mount |
| Model # | LED-30095 WH |
| Size | 7" |
| Color/Finish | Round, Matte White Finish |
| Notes | |
| Price Point | |
| Product Type | |
| Patio Light Legacy Lighting 6" 3000K 57697WTBK Square Matte Black | |
|---|---|
|
|
| Location | Patio |
| Manufacturer | Legacy Lighting |
| Description | 6” 3000K LED Flush Mount |
| Model # | 57697WTBK |
| Size | 6" |
| Color/Finish | Square, Matte Black Finish |
| Notes | Wet Label / Rated in Bathroom Areas and Balcony Areas |
| Price Point | |
| Product Type | |
| Patio Light Legacy Lighting Wall LOL470BK Matte Black | |
|---|---|
|
|
| Location | Patio |
| Manufacturer | Legacy Lighting |
| Description | Wall/Step Light |
| Model # | LOL470BK |
| Size | 3.75"EXT X 7-7/8"H X 4.5"W2 |
| Color/Finish | Matte Black |
| Notes | Wet Label |
| Price Point | |
| Product Type | |
| Vanity Light Legacy Lighting LED-22464 BK 24" Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Legacy Lighting |
| Description | Sconce |
| Model # | LED-22464 BK |
| Size | 24” wide |
| Color/Finish | Black |
| Notes | Install horizontally above mirror, one fixture per sink bowl. When one sink is provided, center single fixture over vanity. When two sinks are provided, center fixture over each sink. |
| Price Point | |
| Product Type | |
| Leviton White Outlet R62-16252-0WS | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Leviton |
| Description | Decora Plus |
| Model # | R62-16252-0WS |
| Size | |
| Color/Finish | White |
| Notes | |
| Price Point | |
| Product Type | |
| Leviton USB Outlets White | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Leviton |
| Description | Decora Plus |
| Model # | T5833-W (Type A and C Charger) |
| Size | |
| Color/Finish | White |
| Notes | Locations as shown in plans |
| Price Point | |
| Product Type | |
| Honeywell Thermostat TH6220WF2006/U White | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Honeywell |
| Description | Lyric T6 Smart Thermostat |
| Model # | TH6220WF2006/U |
| Size | |
| Color/Finish | White |
| Notes | |
| Price Point | |
| Product Type | |
| Light Switches Leviton White R72-05601-2WS | |
|---|---|
|
|
| Location | Units |
| Manufacturer | Leviton |
| Description | Decora Plus |
| Model # | R72-05601-2WS |
| Size | |
| Color/Finish | White |
| Notes | 1 dimmer switch per unit (kitchen Pendants) |
| Price Point | |
| Product Type | |
Moulding Trimwork
| Location | Manufacturer | Description | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|
| Units | Base Board | 1" x 6" nominal | Solid wood - Contemporary eased edge. | NOVEL |
|
|||
| Units | Door Trim | 1"x 4" sides, 1"x 6" header | FJP - Contemporary square profile. Header flush with casings. No extensions provided. |
|
||||
| Units | Window Apron & Stool | 4" apron 6” stool | FJP - Contemporary square profile |
|
||||
| Unit Islands | Unit Island Wood Post | 3x3 | Painted to match cabinets | Flooring to extend underneath island post. Perimeter of island posts to be wrapped with shoe mold after post is leveled. |
|
|||
| Unit Islands | Trim under Counter | ¼” x 1-5/16” | Applied under countertops to cover gap between drywall and countertop |
|
||||
| Closets | Organized Living | Closet Shelving | Per Drawings | Chrome Rod/White Bracing with White Shelves | Size/quantity per drawings. Provide two shelves on long walls and single shelf on short wall. Kyle Wilkins kwilkins@organizedliving.com (513) 205-2527 |
|
| Base Board 1" x 6" Paint Grade | |
|---|---|
|
|
| Location | Units |
| Manufacturer | |
| Description | Base Board |
| Size | 1" x 6" nominal |
| Color/Finish | |
| Notes | Solid wood - Contemporary eased edge. |
| Price Point | |
| Product Type | NOVEL |
| Door Trim 1"x4", 1"x6" Paint Grade Pine | |
|---|---|
|
|
| Location | Units |
| Manufacturer | |
| Description | Door Trim |
| Size | 1"x 4" sides, 1"x 6" header |
| Color/Finish | |
| Notes | FJP - Contemporary square profile. Header flush with casings. No extensions provided. |
| Price Point | |
| Product Type | |
| Window Apron & Stool 4", 6" Paint Grade Pine | |
|---|---|
|
|
| Location | Units |
| Manufacturer | |
| Description | Window Apron & Stool |
| Size | 4" apron 6” stool |
| Color/Finish | |
| Notes | FJP - Contemporary square profile |
| Price Point | |
| Product Type | |
| Unit Island Wood Post 3x3 Paint Grade Wood | |
|---|---|
|
|
| Location | Unit Islands |
| Manufacturer | |
| Description | Unit Island Wood Post |
| Size | 3x3 |
| Color/Finish | Painted to match cabinets |
| Notes | Flooring to extend underneath island post. Perimeter of island posts to be wrapped with shoe mold after post is leveled. |
| Price Point | |
| Product Type | |
| Trim Under Counter 1/4" x 1-5/16" Paint Grade Pine | |
|---|---|
|
|
| Location | Unit Islands |
| Manufacturer | |
| Description | Trim under Counter |
| Size | ¼” x 1-5/16” |
| Color/Finish | |
| Notes | Applied under countertops to cover gap between drywall and countertop |
| Price Point | |
| Product Type | |
| Closet Organizer Organized Living | |
|---|---|
|
|
| Location | Closets |
| Manufacturer | Organized Living |
| Description | Closet Shelving |
| Size | Per Drawings |
| Color/Finish | Chrome Rod/White Bracing with White Shelves |
| Notes | Size/quantity per drawings. Provide two shelves on long walls and single shelf on short wall. Kyle Wilkins kwilkins@organizedliving.com (513) 205-2527 |
| Price Point | |
| Product Type | |
Plumbing Fixtures
| Location | Manufacturer | Description | Model # | Size | Color/Finish | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Kitchen | Pfister | Bruton 1-Handle Culinary Pull-Down Kitchen Faucet Deck plate not provided with fixture | GT529-BRUB | Matte Black | Provide with 1.5 GPM aerator. Single hold with pull down spray Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Pfirst Modern Single Control Lavatory Faucet | LG42-PFM0B | Matte Black | Provide with 1.2 GPM aerator. Single Hole Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Pfirst Modern Trim (less shower head) | R89-8PFMB | Matte Black | 1-Handle, Tub & Shower Combo. Drain/trim to match (separate shower head). Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Pfirst Modern Trim (less shower head) | R89-7PFMB | Modern Black | 1-Handle Shower Trim. Drain/trim assemblies to match (separate shower head). Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Showerhead (all tubs /showers) with straight shower arm (stand-alone shower) Bronson Raincan Showerhead | 973-103B | Matte Black | 1.75 GPM shower head waterline stub should be @ 7’ 6” AFF. Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Showerhead (all tubs /showers) with straight shower arm (stand-alone shower) Bronson Raincan Showerhead | 973-313B (head) | Matte Black | 1.75 GPM shower head waterline stub should be @ 7’ 6” AFF. Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | ADA Handheld Shower with Slide Bar (or equivalent) | LG16-500B | Matte Black | 1.75 GPM hand held shower head. Provide in ADA Units. Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Contempra Tub and Shower Trim + Deckard Shower head | LG89-7NCB | Matte Black | 1-Handle, Tub & Shower Combo. Provide with 1.5 GPM shower head Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Deckard shower head | J15-DA0B | Matte Black | 1.8 GPM flow rate. |
|
|||
| Bathroom | Pfister | Deckard | 016-DA1B | Matte Black | Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
|||
| Bathroom | Pfister | Universal Mixing Valve | JX8-340A | Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
|
||||
| Tub/shower | Sterling (or equal) | Forum Vikrell Tub | 71621112 | 60"x36"x21" | White | Provide vinyl quarter round along base of pan. Drain/trim to match shower fixture finish. Giovanna Carchidi giovanna.carchidi@kohler.com (267) 530-3363 |
|
||
| Bathroom | Proflo | 1.28 gpf with plastic seat. | PF1401TWH | 15” bowl height | White | Soft close seat and lid |
|
||
| Bathroom | Proflo | 1.28 gpf with plastic seat. | PF1403TWH | 17” bowl height | White | Soft close seat and lid |
|
||
| Shower Pan | Sterling | Guard + Shower Pan | 95079-0 | Dimensions per Architectural Plans | White | Provide vinyl quarter round along base of pan. Drain to match shower fixture finish. |
|
||
| Bathroom | Barrier Free | Shower Pan with Removable Threshold | P6331A2B | Dimensions per Architectural Plans | White | Drain to match shower fixture finish. Provide with cultured marble side panels. |
|
| Kitchen pfister Faucet GT529-BRUB Matte Black | |
|---|---|
|
|
| Location | Kitchen |
| Manufacturer | Pfister |
| Description | Bruton 1-Handle Culinary Pull-Down Kitchen Faucet Deck plate not provided with fixture |
| Model # | GT529-BRUB |
| Size | |
| Color/Finish | Matte Black |
| Notes | Provide with 1.5 GPM aerator. Single hold with pull down spray Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Bathroom Pfister Faucet LG42-PFM0B Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Pfirst Modern Single Control Lavatory Faucet |
| Model # | LG42-PFM0B |
| Size | |
| Color/Finish | Matte Black |
| Notes | Provide with 1.2 GPM aerator. Single Hole Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Tub & Shower Pfister Trim R89-8PFMB Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Pfirst Modern Trim (less shower head) |
| Model # | R89-8PFMB |
| Size | |
| Color/Finish | Matte Black |
| Notes | 1-Handle, Tub & Shower Combo. Drain/trim to match (separate shower head). Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Shower Pfister Trim R89-7PFMB Modern Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Pfirst Modern Trim (less shower head) |
| Model # | R89-7PFMB |
| Size | |
| Color/Finish | Modern Black |
| Notes | 1-Handle Shower Trim. Drain/trim assemblies to match (separate shower head). Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Shower arm Pfister 973-103B Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Showerhead (all tubs /showers) with straight shower arm (stand-alone shower) Bronson Raincan Showerhead |
| Model # | 973-103B |
| Size | |
| Color/Finish | Matte Black |
| Notes | 1.75 GPM shower head waterline stub should be @ 7’ 6” AFF. Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Shoer head Pfister Matte Black 973-313B | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Showerhead (all tubs /showers) with straight shower arm (stand-alone shower) Bronson Raincan Showerhead |
| Model # | 973-313B (head) |
| Size | |
| Color/Finish | Matte Black |
| Notes | 1.75 GPM shower head waterline stub should be @ 7’ 6” AFF. Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| ADA Tub/Shower Pfister Handheld Shower LG16-500B Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | ADA Handheld Shower with Slide Bar (or equivalent) |
| Model # | LG16-500B |
| Size | |
| Color/Finish | Matte Black |
| Notes | 1.75 GPM hand held shower head. Provide in ADA Units. Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Tub/Shower Head and Trim Pfister LG89-7NCB Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Contempra Tub and Shower Trim + Deckard Shower head |
| Model # | LG89-7NCB |
| Size | |
| Color/Finish | Matte Black |
| Notes | 1-Handle, Tub & Shower Combo. Provide with 1.5 GPM shower head Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Shower Heads Pfister J15-DA0B Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Deckard shower head |
| Model # | J15-DA0B |
| Size | |
| Color/Finish | Matte Black |
| Notes | 1.8 GPM flow rate. |
| Price Point | |
| Product Type | |
| Shower Diverter Trim Pfister 016-DA1B Matte Black | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Deckard |
| Model # | 016-DA1B |
| Size | |
| Color/Finish | Matte Black |
| Notes | Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Pfister Universal Mixing Valve JX8-340A | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Pfister |
| Description | Universal Mixing Valve |
| Model # | JX8-340A |
| Size | |
| Color/Finish | |
| Notes | Shannon Irby shannon.irby@spectrumbrands.com (561) 345-0861 |
| Price Point | |
| Product Type | |
| Tub Sterling 71621112 | |
|---|---|
|
|
| Location | Tub/shower |
| Manufacturer | Sterling (or equal) |
| Description | Forum Vikrell Tub |
| Model # | 71621112 |
| Size | 60"x36"x21" |
| Color/Finish | White |
| Notes | Provide vinyl quarter round along base of pan. Drain/trim to match shower fixture finish. Giovanna Carchidi giovanna.carchidi@kohler.com (267) 530-3363 |
| Price Point | |
| Product Type | |
| Toilet Proflo PF1401TWH White | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Proflo |
| Description | 1.28 gpf with plastic seat. |
| Model # | PF1401TWH |
| Size | 15” bowl height |
| Color/Finish | White |
| Notes | Soft close seat and lid |
| Price Point | |
| Product Type | |
| ADA Toilet Proflo PF1403TWH White 17" | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Proflo |
| Description | 1.28 gpf with plastic seat. |
| Model # | PF1403TWH |
| Size | 17” bowl height |
| Color/Finish | White |
| Notes | Soft close seat and lid |
| Price Point | |
| Product Type | |
| Shower Pan Sterling 95079-0 White | |
|---|---|
|
|
| Location | Shower Pan |
| Manufacturer | Sterling |
| Description | Guard + Shower Pan |
| Model # | 95079-0 |
| Size | Dimensions per Architectural Plans |
| Color/Finish | White |
| Notes | Provide vinyl quarter round along base of pan. Drain to match shower fixture finish. |
| Price Point | |
| Product Type | |
| Roll-in Shower Pan Barrier Free P6331A2B White | |
|---|---|
|
|
| Location | Bathroom |
| Manufacturer | Barrier Free |
| Description | Shower Pan with Removable Threshold |
| Model # | P6331A2B |
| Size | Dimensions per Architectural Plans |
| Color/Finish | White |
| Notes | Drain to match shower fixture finish. Provide with cultured marble side panels. |
| Price Point | |
| Product Type | |
Window Treatments
| Location | Manufacturer | Description | Model # | Size | Color/Material | Notes | Price Point | Product Type | Image |
|---|---|---|---|---|---|---|---|---|---|
| Unit Windows | Hunter Douglas | 2" Faux Woods Blind | Everywood | Per Drawings | Match Window Frames | Inside mount - smooth finish - contemporary valence option; Cordless Option | NOVEL, RENDER, HARMON |
|
| Blinds Hunter Douglas 2" Everywood | |
|---|---|
|
|
| Location | Unit Windows |
| Manufacturer | Hunter Douglas |
| Description | 2" Faux Woods Blind |
| Model # | Everywood |
| Size | Per Drawings |
| Color/Material | Match Window Frames |
| Notes | Inside mount - smooth finish - contemporary valence option; Cordless Option |
| Price Point | |
| Product Type | NOVEL, RENDER, HARMON |
